Live Webinar: The Mathematics Behind Focus Depth in Phased Array
Webinar
Learn the mathematics behind phased array focus depth — calculate optimal settings, understand wave behavior, and improve resolution and sensitivity for ultrasonic inspections. Designed for Level II and III inspectors.
Credit Info
- Contact Hours: 1
- IACET CEUs: .1
- Valid for ASNT Level III recertification: Yes
- Renewal Category: D
Course Overview
Participants will learn how focus depth in phased array works and how to correctly calculate, set up, and achieve optimal resolution and sensitivity at the focal spot, ensuring maximum energy and acoustic pressure.
This session emphasizes the mathematics behind phased array. Attendees will explore the real waveforms at the focal spot and learn how to design effective scan plans.
Upon Completion, Learners Will Be Able To:
- Understand wave behavior at the focal depth
- Calculate the optimal number of active elements for each configuration
- Identify the correct focus depth for inspections
- Select the most suitable probe for specific applications
Meet the Speaker
Luis Montoya
Luis is a Phased Array Inspector with over 18 years of experience, having performed more than 20,000 weld inspections and interpretations. Winner of 1st place in the Ultrasonic Competition at ASNT 2025. Certified CWI and PAUT /AUT Inspector. Developer of an inspection system to measure underwater surface corrosion. Extensive field experience across Colombia, Ecuador, Peru, Chile, Argentina, Bolivia, Panama, and the Dominican Republic. Since 2023, founder and manager of his own company, dedicated to teaching, advising, and training inspectors in NDT and welding.
