Virtual Section Meeting: Assessing Radiographs of SAW Stainless-Steel for Mottled Indications
Webinar
Discover why stainless steel weld x-rays can look flawed when they’re not, and learn how equipment settings and material factors create these tricky images.
Credit Info
- Contact Hours: 1
- IACET CEUs: NA
- Valid for ASNT Level III recertification: Yes
Course Overview
When radiographing an austenitic stainless-steel weld with an appreciable weld deposit size, selecting a low radiographic kilovoltage (keV) can contribute to producing a radiographic indication that is not an imperfection or flaw. The combination of the above can create a mottled radiographic indication that radiographers may incorrectly identify as incomplete fusion or incomplete penetration. This presentation addresses the contributors to this condition; radiographically and metallurgically.
Upon Completion, Learners Will Have Covered:
- Compare the differences between x-ray and gamma ray radiography on the same subject.
- Analyze the impact of changing mA and kV settings when radiographing stainless steel welds.
- Explain the metallurgical and chemical contributors that affect radiographic quality in stainless steel (SAW) welds.
Meet the Speaker
Marty Wenzig
An ASNT Fellow and Chair of the Authorized Training Organization (ATO) Program. He serves on multiple ASNT committees, including Advocacy, SNT-TC-1A, CP-189, Approved Standards Users, and Council of Fellows. Marty holds undergraduate degrees in Welding Technology and Material Sciences and has held numerous credentials, including Professional Engineer (CA), ASNT NDT Level III, ACCP Professional Level III, AWS-CWI/CWE, ISO-9712 / EN 473 Level 3, and NAVSEA Examiner. He is a Principal Consultant at Quality Consultants and previously held leadership roles at Industrial Testing Laboratory Services, ITLS Nuclear Technical Institute, SPEC Group, and Ionics Incorporated. He authored the ASNT CP-189 Audit Checklist, contributed to ASNT publications, and has written articles for Materials Evaluation, Power Magazine, and Quality Magazine.
